SPE Spin Centrifuge Columns
MonoSpin Affinity Columns (PBA, ME, TiO, Phospholipid)
MonoSpin is a monolithic SPE column excellent for the small volume sample with an easy and quick operation by centrifuge.
Features
- Easy-to-Operate
- High Throughput and Rapid Operation for Biological Sample
- Ideal for Small Sample Volumes
- Allows selection of functional groups such as columns with wide adaptability and columns capable of selective purification and concentration

Functional Group
MonoSpin PBA

High selectivity columns with phenyl boronic acid. Optimal for selective extraction of cis diols, such as catecholamines.
MonoSpin ME

Bonded with iminodiacetic acid. Optimal for the recovery of trace metals.
MonoSpin TiO

Monolith skeleton coated with titanium dioxide. Excellent for the adsorption and removal of phospholipids.
MonoSpin Phospholipid

Monolith skeleton coated with TiO2 and ZrO2. Excellent for the adsorption and removal of phospholipids.
Configurations
S Type: Spin Column

Sample volume: up to 800 μL
Eluent volume: 50 μL - 800 μL
Spin Column is used setting with 1.5 mL and 2 mL micro tubes.
L Type: Large Volume Reservoir

Sample volume: up to 8 mL
Eluent volume: 0.5 mL - 8 mL
Large Volume Reservoir is used setting with 50 mL centrifuge tub
96-well Plate

Note) Reservoir shape is different upon the type of the columns.
MonoSpin Affinity Columns
Funcational Group | Format | Qty. | Cat.No. |
---|---|---|---|
PBA | S Type | 50pcs | 5010-21715 |
PBA | S Type | 100pcs | 5010-21716 |
ME | S Type | 50pcs | 5010-21737 |
ME | S Type | 100pcs | 5010-21738 |
ME | L Type | 30pcs | 7510-11325 Discontinued |
TiO | S Type | 50pcs | 5010-21705 |
TiO | S Type | 100pcs | 5010-21706 |
Phospholipid | S Type | 50pcs | 5010-21698 |
Phospholipid | S Type | 100pcs | 5010-21699 |
Phospholipid | L Type | 30pcs | 7510-11326 |
PBA | 96well Type | 1pc | 5010-21902 |
Note) The MonoSpin contains the same number of collection tubes (1.5 mL) and waste liquid tubes (2 mL). The MonoSpin L does not have any collection tubes nor waste liquid tubes. Prepare a 50 mL centrifuge tube separately.
